BEF-FA-036-060REC

BEF-AD-G14-G12B-PXX SCREW-IN ADAPTER — вариант продукции серии Фланцы и патрубки из группы «Системы крепления».

• Группа аксессуаров: Mounting systems
• Семейство аксессуаров: Brackets
• Описание: Process adapter for pressure sensors with G 1/4” female thread; attachment on sensor side: G 1/4”B (according to EN 837-1) including seal (stainless steel); connection on process side: G 1/2”B (according to EN 837-1) including seal (stainless steel); width across flats: 27; pressure resistance according to standard, but max. 600 bar (possible classification according to Pressure Equipment Directive (DGRL) is application-specific and therefore the responsibility of the user/operating entity.)
• Материал: Stainless steel 1.4404

BEF-AD-G14-G14B06-PXX — вариант продукции серии Фланцы и патрубки из группы «Системы крепления».

• Группа аксессуаров: Mounting systems
• Семейство аксессуаров: Brackets
• Описание: Process adapter for pressure sensors with G 1/4” female thread; material: stainless steel 1.4404, width across flats: 27; connection on sensor side: G 1/4”B (according to EN 837-1) including seal (stainless steel); connection on process side:G 1/4”B (according to EN 837-1) with 0.6 mm erosion drilling for pressure peak damping, including seal (stainless steel); pressure resistance according to standard, but max. 600 bar (possible classification according to Pressure Equipment Directive (DGRL) is application-specific and therefore the responsibility of the user/operating entity.)
• Материал: Stainless steel 1.4404

BEF-AD-G14-R14-PXX SCREW-IN ADAPTER — вариант продукции серии Фланцы и патрубки из группы «Системы крепления».

• Группа аксессуаров: Mounting systems
• Семейство аксессуаров: Brackets
• Описание: Process adapter for pressure sensors with G 1/4” female thread; attachment on sensor side: G 1/4”B (according to EN 837-1) including seal (stainless steel); connection on process side: R 1/4”A (according to ISO 10226); width across flats: 21; pressure resistance according to standard, but max. 600 bar (possible classification according to Pressure Equipment Directive (DGRL) is application-specific and therefore the responsibility of the user/operating entity.)
• Материал: Stainless steel 1.4404

BEF-CFSN12-FTS1 — вариант продукции серии Фланцы и патрубки из группы «Системы крепления».

• Группа аксессуаров: Mounting systems
• Семейство аксессуаров: Flanges and nozzles
• Описание: Compression fitting for T-Easic FTS, ½'' NPT Hygienic process connection adapter for LFP, 1” and 1 ½” tri-clamp, material 1.4404 (Ra<= 0.8 µm)
